Advantages of additive manufacturing can be deployed to reduce costs, shorten time to market, and enable the production of parts too complex to be manufactured using traditional methods. The PAEK incumbent materials on the market today, although used in some AM applications, were designed for conventional manufacturing methods, such as machining and injection moulding. Because of this, they have some features that aren’t optimal for additive manufacturing processes. A first generation of PAEK material for Laser Sintering can only be recycled in a very low extent and required nearly full refresh of the printing bed with new powder, and PEEK filaments available for FF have poor interlayer bonding, leading to a loss in Z-strength.
The new polymer grades developed by Victrex have shown encouragingly low refresh rates (improves recycle for unsintered powder) with similar mechanical properties in LS, and in FF good mechanical properties and printability.
John Grasmeder, Chief Scientist at Victrex explains: “Breakthrough technology is paving the way for an exciting future for Additive Manufacturing PAEK. The powder recycle work for Laser Sintering, using the new Victrex development polymer grades has gone very well, with no measurable loss of properties when test components were made from partially recycled powder. We believe it will be possible to re-use all of the non-sintered powder that is recovered after a build run. This will result in a significant reduction in material costs compared to current PolyArylEtherKetone materials where up to 40% of the polymer is wasted and cannot be recycled.”
Partnering for progress in AM
Victrex is leading a consortium of companies and institutions and was awarded funding from the UK's agency for innovation, Innovate UK, in 2016 to carry out intensive pioneering research and development to advance AM technologies, in particular high-temperature, affordable polymer composites for AM aerospace applications. The other members of the consortium are Airbus Group Innovations, EOS, University of Exeter Centre for Additive Layer Manufacturing (CALM), E3D-Online, HiETA Technologies, South West Metal Finishing, and 3T-RPD.
The new VICTREX PAEK filament and powder tie in with technologies developed by other members of this Innovate UK project. EOS has recently released a new automation-ready manufacturing platform for laser sintering of plastic parts on an industrial scale (EOS P 500) with the capability to print high-performance polymers at high temperatures. Selected materials of the consortium are evaluated at EOS R&D facilities for processability on current EOS systems as well as for use with the EOS P 500 platforms. Victrex is planning to continue pre-commercial testing of a new PAEK filament product in conjunction with consortium partner E3D, who has recently commercially released a new water-cooled filament extruder head especially optimised for this new PAEK filament.
Victrex has more than 35 years of knowledge in developing and applying novel PAEK/PEEK* polymer based solutions spanning polymers, forms and parts in selected areas. The lightweight, high-strength PEEK polymer uniquely supports a combination of multiple requirements as it provides high resistance to wear, high temperatures, fatigue and aggressive fluids/chemicals, and together these properties can contribute to more design freedom and cost-efficient production.
* PEEK, Polyetheretherketones such as VICTREX™ PEEK are a member of the PAEK, Polyaryletherketone, family of high-performance thermoplastics.
** The following companies partner in the Additive Manufacturing consortium headed by Victrex and funded by Innovate UK: Airbus Group Innovations, 3T-RPD Ltd, E3D-Online, EOS, University of Exeter Centre for Additive Layer Manufacturing (CALM), HiETA Technologies, South West Metal Finishing, Victrex
About Innovate UK
Innovate UK is the UK’s innovation agency. It works with people, companies and partner organisations to find and drive the science and technology innovations that will grow the UK economy. For further information visit www.innovateuk.gov.uk
